XE155ECR(Double boom)

E Series
XE155ECR(Double boom)
Operating weight(Kg): 16760 Rated power(kW/rpm): 90 Engine model(-): Cummins B4.5
XE155ECR(Double boom)

The XE155ECR makes handling your task efficient and comfortable. The optimized Kawasaki-KPM hydraulic system makes sure that all that engine power is used in the best possible way by delivering accurate maximum pumping in a smooth way. It is adopts PTO pump to optimise pump flow rate and power at various working conditions, combined action is more coordinated and precise with independent pump control of rotating implement lines. All that power has reliably increased the digging power, the lifting capacities, and the traction force. Greater fuel efficiency means you can keep costs down and reduce environmental imp.

XE155ECR(Double boom)
  • Parameters
  • Images Gallery
  • Cases
PARAMETERS
Item Unit Parameter
Operating weight Kg 16760
Rated power kW/rpm 90
Engine model - Cummins B4.5
Bucket capacity 0.6
Emission standard - Euro V
Maximum torque/speed N.m 500/1500
Displacement L 4.5
Travel speed km/h 4.7/2.9
Swing speed r/min 11.3
Bucket digging force kN 107
Arm digging force kN 80
Images Gallery
